P0.7 Indoor Small Pixel Pitch Seamless 4K LED Display with Full flip-chip COB process

Brand Name : Visual World

Model Number : P0.7

Certification : EMC,CE,FCC,ROHS

Place of Origin : CN

MOQ : Negotiate

Price : Negotiate

Payment Terms : T/T

Supply Ability : 5000 sqm/month

Delivery Time : 12 work days

Packaging Details : Plywood case, export carton box

Pixel Pitch : P0.7/P0.9/P1.2

Refresh Rate : >3840Hz

Brightness : 600-800nits

Durability : 100000 Hours

Cabinet Material : Die-casting Aliuminum

Display Type : LED

Size : 600x337.5mm

Maintenance : Front/Rear Service

Contact Now

P0.7 Indoor Small Pixel Pitch Seamless 4K LED Display with Full flip-chip COB process

Product Description:

The XMETA i series LED panels which make sophisticated fine pitch LED video wall, are developed to play into the demands for permanent video installations. Uncomplicated installation, adaptable design, easy low-key and low-cost maintenance go hand-in with high-end performance and unequaled visual qualities.

Features:

  • ultra-light&ultra-thin design, cabinet thickness ≤35mm, single cabinet weight ≤4.6kg, to save space for users, reduce load requirements.
  • Front and rear maintenance design, easy installation and maintenance, wider application scenarios.
  • small module (4×2) splicing, disassembly is not easy to hit the lamp, good maintainability, low spare parts cost.
  • the main frame and back cover die-casting design, high precision, the module supports Z-axis adjustment, flatness ≤0.1mm.
  • the module adopts hard connection mode, fast installation and maintenance, stable signal.
  • the interior of the cabinet to support up and down left and right lines, to meet a variety of customer needs, the interior is clean and beautiful.

Technical Parameters:

Product Model:

P0.7

P0.9

P1.2

Pixel Pitch:

0.7 mm

0.9 mm

1.2 mm

LED package type

Flip chip technology

Flip chip technology

Flip chip technology

Cabinet Dimension:

600×337.5x35 mm

600×337.5x35 mm

600×337.5x35 mm

Cabinet Weight:

4.6kg

4.6kg

4.6kg

Cabinet Material:

Die-casting Aluminum

Die-casting Aluminum

Die-casting Aluminum

Brightness:

>600 nits

>600 nits

>600 nits

Max/Avg Power:

420/65 W/sqm

395/55 W/sqm

395/55 W/sqm

Maintenance:

Front/Rear service

Front/Rear service

Front/Rear service

Environment:

Indoor Use

Indoor Use

Indoor Use

IP Rating:

F: IP30, R: IP45

F: IP30, R: IP45

F: IP30, R: IP45

Refresh Rate:

>3840 Hz

>3840 Hz

>3840 Hz

Installation Type:

Mounting/Hanging

Mounting/Hanging

Mounting/Hanging

Gray Scale:

16 bit

16 bit

16 bit

Viewing Angle:

H:170°;V:170°

H:170°;V:170°

H:160°;V:160°

Operational Temp:

-20℃~+50℃

-20℃~+50℃

-20℃~+50℃

Operational Humidity:

10%~90% RH

10%~90% RH

10%~90% RH

Applications:

- Advertising and marketing displays

- Corporate events and conferences

- Concerts and live performances

- Sports events and stadiums

- Control rooms and command centers

- Retail stores and shopping malls

- Museums and galleries

- And more!

P0.7 Indoor Small Pixel Pitch Seamless 4K LED Display with Full flip-chip COB process

Packing and Shipping:

Packaging

The Fine Pixel Pitch LED Display is first wrapped in a protective layer of bubble wrap to prevent any damage during transportation. It is then placed in a sturdy cardboard box with foam padding to provide additional protection.

The box is then sealed and labeled with the product name, model number, and shipping information.

Shipping

We offer multiple shipping methods to ensure timely and secure delivery of our Fine Pixel Pitch LED Display.

For domestic orders, we use reliable courier services such as FedEx, UPS, and DHL. For international orders, we use air or sea freight depending on the customer's preference and location.

Our team carefully tracks and monitors the shipment until it reaches its final destination.

Upon arrival, the Fine Pixel Pitch LED Display is inspected and tested to ensure it is in perfect working condition before being delivered to the customer.

FAQ:

Q1:what can you buy from us?
A1:Led Display,outdoor led display,led billboard,LED module,indoor led display

Q2. What pixel pitch can this panel be compatible with?

This model works with P0.7, P0.9, P1.2


Q3:what services can we provide?
A3:Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU
Accepted Payment Currency: USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:

English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
